NSG

Last updated: December 15, 2024

Network Security Groups (NSGs) are helpful in defining the traffic rules in a VNet. By defining the rules, you'll specify the inbound and outbound traffic regulations and protect your network from unintended traffic.

Setting up a traffic rule in a VNet is done in 2 steps:

Define a NSG and traffic rules
Attach rules to the specific subnets

You can define an NSG as follows:

resource "azurerm_network_security_group" "nsg" {
  name                = "${local.resource_prefix}_nsg"
  location            = local.location
  resource_group_name = azurerm_resource_group.rg.name
  tags                = local.tags

  security_rule {
    name                       = "deny-http"
    priority                   = 100
    direction                  = "Outbound"
    access                     = "Deny"
    protocol                   = "Tcp"
    source_port_range          = "*"
    destination_port_range     = "80"
    source_address_prefix      = "*"
    destination_address_prefix = "*"
  }

  security_rule {
    name                       = "allow-https"
    priority                   = 110
    direction                  = "Inbound"
    access                     = "Allow"
    protocol                   = "Tcp"
    source_port_range          = "*"
    destination_port_range     = "443"
    source_address_prefix      = "*"
    destination_address_prefix = "*"
  }

  depends_on = [
    azurerm_resource_group.rg
  ]
}

The example above defines two inbound rules, one to deny HTTP traffic and one to allow HTTPS traffic.

Next, you need to attach the NSG to the desired subnet, e.g.

resource "azurerm_subnet_network_security_group_association" "hub-sql-subnet" {
  subnet_id                 = azurerm_subnet.hub-sql-subnet.id
  network_security_group_id = azurerm_network_security_group.nsg.id
  depends_on = [
    azurerm_subnet.hub-sql-subnet,
    azurerm_network_security_group.nsg
  ]
}
